PLC Programming I/O modules on the NX CPU Unit or Coupler Unit NX-ID5342 NX series

Features
• High-speed I/O refreshing using the EtherCAT coupler
• I/O refreshing synchronized with the control cycle of the controller (synchronous refreshing)
• Time-stamp inputs and outputs anywhere in the EtherCAT network can be independently controlled with
sub-microsecond accuracy
• Detachable terminals for easy maintenance
• Screwless Push-In Plus terminal block or MIL/Fujitsu connector speeds up installation
• Compact with a width of 12 mm per unit (connector type: 30 mm)
• 4, 8, 16 or 32 inputs for flexible I/O configuration (NX-ID/IA)
• 2, 4, 8, 16 or 32 outputs for flexible I/O configuration (NX-OD/OC)
• Connect to the CJ PLC using the EtherNet/IPTM bus coupler

System Configuration in the Case of a Communication Control Unit
The following figure shows a system configuration when a group of NX Units is connected to an NX-series Communication Control Unit. To
configure a Safety Network Controller, mount the Safety CPU Unit, which is one of the NX Units, to the CPU Rack of the Communication Control
Unit.
You cannot connect a Communication Control Unit with Digital I/O Units that support input refreshing with input changed time or output refreshing
with specified time stamp.
