    BH1730FVC-TR Digital 16bit Serial Output TypeAmbient Light Sensor IC

    Ask Lasest Price
    Brand Name : ROHM
    Model Number : BH1730FVC-TR
    Certification : rohs
    Price : consult with
    Payment Terms : T/T,Western Union
    Supply Ability : 10000
    Delivery Time : 5-8day
    • Product Details
    • Company Profile

    BH1730FVC-TR Digital 16bit Serial Output TypeAmbient Light Sensor IC

    BH1730FVC-TR Digital 16-bit Serial Output Ambient Light Sensor IC
    The BH1730FVC-TR is a digital 16-bit serial output ambient light sensor IC designed for precise light measurement applications across various lighting conditions.
    Key Features
    • I2C bus interface with f/s mode support and slave address "0101001"
    • Dual outputs with peak wavelengths for visible light and infrared light
    • Integrated illuminance to digital converter
    • Low current consumption with power down function
    • 50Hz/60Hz light noise rejection function
    • Minimal light source dependency (incandescent, fluorescent, halogen, white LED, sunlight)
    • Built-in interrupt function
    • Sensitivity adjustment for optical window compensation
    Applications
    • LCD TVs
    • Mobile Phones
    • Tablet PCs
    • Notebook Computers
    • Digital Cameras
    • Portable Gaming Devices
    Pin Configuration
    Pin No.Pin NameFunction
    1VCCPower supply terminal
    2INTINT pin output terminal. If not in use, connect to GND or leave open.
    3GNDGND terminal
    4SDAI2C bus interface SDA terminal
    5DVII2C bus I/O voltage
    6SCLI2C bus interface SCL terminal
    BH1730FVC-TR Ambient Light Sensor IC diagram BH1730FVC-TR sensor application example BH1730FVC-TR technical specifications
    Packaging & Shipping
    Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their specific requirements.
